Vestil VHPS-2000-AA Manual Stacker Adjustable Forks/Legs 2K
$2,603.95
Vestil Manual Stacker Adjustable Forks/Legs 2K VHPS-2000-AA
- Stacker design meets the most challenging tasks
- Unique design is maintenance free and easy to use
- Full height push handle allows for easy steering
- Winch design offers easier and safer lifting
| Uniform Capacity (lbs.) | 2000 |
| Lowered Height (in.) | 1-3/8 |
| Raised Height (in.) | 63 |
| Horizontal Load Center (in.) | 24 |
| Straddle Leg Minimum (in.) | 34 (I.D) |
| Straddle Leg Maximum (in.) | 50 (I.D) |
| Fork Adjustment Minimum (in.) | 6 (O.D) |
| Fork Adjustment Maximum (in.) | 24 (O.D) |
| Rear Caster Diameter (in.) | 7 |
| Rear Caster Width (in.) | 2 |
| Front Caster Diameter (in.) | 4 |
| Front Caster Width (in.) | 2-29/32 |
| Lift per Handle Revolution (in.) | 1 |
| Individual Fork Width (in.) | 3-15/16 |
| Fork Length (in.) | 42-1/8 |
| Operation | Hand Winch |
| Min. Travel Distance (in.) | 36 |
| Max. Travel Distance (in.) | 64 |
| Leg Width (in.) | 4 |
